Comprehensive Sign Support Category
A metal road sign post is a general category of support structure used for warning signs, prohibition signs, instruction signs, directional signs, and large exit advance panels.
Depending on the sign dimensions and available roadside space, the structure can use a single post, double post, single-cantilever F-type, or double-cantilever T-type configuration.
A single-post structure is suitable for smaller roadside signs. Double posts provide two support points for wider sign panels. Cantilever systems extend the panel toward or over one or more lanes where a standard roadside position does not provide the required sign location.
The product can be used on highway shoulders, outside guardrail lines, at interchanges, ramp exits, service areas, and multi-lane road sections.
Diameter, Thickness, and Height Range
Single-post sizes include Φ114 mm, Φ140 mm, Φ165 mm, and Φ219 mm. Their wall thickness is normally 4–6 mm, with a typical height of 3.5–5 m.
Double-post structures use Φ165 mm or Φ219 mm posts, with wall thicknesses of 5–8 mm and heights of 4–6 m.
Cantilever main posts can use Φ273 mm, Φ325 mm, Φ377 mm, or Φ426 mm pipes. Available wall thicknesses range from 6 mm to 12 mm. Cantilever arms can extend from 3 m to 12 m, and the total structure height is normally 6–9 m.
The overall product range therefore covers pole diameters from Φ114 mm to Φ426 mm, wall thicknesses from 4 mm to 12 mm, and structure heights from 3.5 m to 9 m.
The final metal road sign post specification should be confirmed according to the sign area, foundation, wind load, and project structural drawings.
Multi-Product Project Supply
Hongrong Traffic supplies traffic signs, sign poles, gantry structures, guardrails, and guardrail posts. This product range allows several traffic safety products to be coordinated within one road project.
The factory uses cutting, welding, and hot-dip galvanizing processes to manufacture pole bodies, flanges, and connection components. The technical team can develop hole positions, component lengths, and installation details according to the drawings.
Specifications, supply methods, and export packing can be adjusted according to the project documents. Customized products enter mass production after first-piece confirmation.
Buyers may arrange factory inspection, production-stage sampling, or third-party inspection before shipment. Material, wall thickness, dimensions, welding, and surface treatment can be included in the agreed inspection scope.
Sign Matching and Installation-Point Packing
The metal road sign post can be supplied together with circular, triangular, and rectangular aluminum traffic signs. Signs, poles, flanges, bolts, and connection parts can be numbered as complete sets according to their installation points.
Long posts and cantilever arms are secured with steel straps and waterproof protection. Timber reinforcement can be added inside the container. Flanges, bolts, and smaller accessories are packed separately.
Production photos and videos can be provided, and large orders may be delivered in batches. Repeat orders using the same drawings can reduce repeated review and production setup work.
After delivery, the buyer should first check the component numbers, flange hole positions, and embedded foundation dimensions. Transport damage should be recorded through photos, videos, and delivery documents so that the after-sales team can review the issue.
Product Specifications
|
Parameter |
Product Configuration |
|
Structural Forms |
Single-post, double-post, F-type cantilever, or T-type cantilever |
|
Pole Diameter Range |
Φ114–426 mm, depending on structure |
|
Wall Thickness Range |
4–12 mm |
|
Structure Height |
3.5–9 m |
|
Cantilever Length |
3–12 m |
