Product Description
Trapezoidal Galvanized Sheet is a roll-formed GI panel with straight-sided, trapezoidal ribs rather than round waves. Produced from hot-dip galvanized steel coil 0.085–1.2 mm thick, with zinc coating 20–300 g/m² and Regular or Big Spangle finish, it is used both as roof cladding and as wall cladding on industrial plants, workshops, and warehouse facades. The flat trapezoidal faces fix cleanly and read as a modern industrial surface, while the rib depth gives stiffness between supports. Rib pitch and height can be roll-formed to a customer drawing, and length is cut to the wall height or roof bay to minimize horizontal joints.
Because the same panel runs on both roof and wall of an industrial building, our workshop can punch, cut, and weld matching accessories (flashing, gussets, angle trims) to the same trapezoidal profile, so the Trapezoidal Galvanized Sheet package arrives as a coordinated roof-and-wall kit rather than sheets alone.
Specifications
|
Material |
Hot-dip Galvanized Steel (GI) |
|
Surface |
Regular Spangle, Big Spangle |
|
Profile |
Trapezoidal Rib (customizable pitch/height) |
|
Thickness |
0.085 – 1.2 mm |
|
Width |
700 – 1250 mm (base sheet) |
|
Zinc Coating |
20 – 300 g/m² |
|
Length |
Customizable |
|
Form |
Trapezoidal Sheet (Roof + Wall) |
|
Application |
Industrial Plant Roofing & Wall Cladding |
|
Custom Options |
Rib Pitch, Rib Height, Thickness, Coating, Length, Matching Trims |
Applications
Industrial Factory Wall Cladding - The flat trapezoidal face reads as a clean industrial facade, and the zinc coating protects against workshop dust and moisture without requiring immediate paint.
Plant and Warehouse Roofing - The trapezoidal rib spans between purlins and directs rain through the flat pan, making it a workhorse roof for production halls and storage buildings.
Combined Roof-and-Wall Package - When a building needs the same profile on roof and walls, one trapezoidal specification simplifies material ordering, fixing details, and end trim design.
Customization
We customize trapezoidal rib pitch, rib height, thickness, coating weight, spangle type, and cut length. Matching flashing, trims, and punched details can be fabricated in-house. OEM/ODM accepted, with drawing review and first-piece approval before batch production.
Packaging & Transportation
Waterproof film wrap, rubber spacers, steel band strapping, internal wooden bracing, and separate packing of accessories and trims. Pallet loading available. A loading video is recorded for every container. EXW is preferred.
FAQ
Q1: Can one trapezoidal profile be used on both roof and wall?
Yes. The trapezoidal rib works as a roof panel and as wall cladding on the same building, which is why industrial plants often standardize on one profile for the whole envelope.
Q2: Do you supply matching flashing and trims?
Yes. Our workshop has punching, cutting, and welding equipment, so we can fabricate matching flashing, angle trims, and gussets to the same trapezoidal profile and pack them separately with the sheet order.
Q3: What is your warranty?
We warrant against defects in raw material and manufacturing workmanship. We respond within 24 hours to after-sales issues. Damage from misuse, improper installation, or environmental exposure beyond the specified coating is not covered.
